| Model | Communication | Reading and discovery | Battery control | Status |
|---|---|---|---|---|
| ASW10kH-T2 | RS485, Monitor RJ45 port 3 | Device identity, battery status and state of charge verified on a physical installation | Charge/discharge commands and normal EMS operation still require an integration test | In beta and available on request |
This validation applies to the named model and communication board only. It does not establish full battery control support for every H-T2 or H-T3 variant.
| Function | Availability | Validation |
|---|---|---|
| Release temporary RS485 scan connections during an I/O reload while retaining saved device connections | In beta and available on request, not yet in the standard release | Software regression checks passed; validation of the correction on a physical controller is pending |
| Device Type | Modbus TCP (Ethernet) | RS485 | Curtailment | Reactive power control |
|---|---|---|---|---|
| ASW LT 125kW | ❌ | ✅ | ✅ | — |
| ASW LT-G2 Pro 3-20kW | ||||
| ASW LT-G3 45-60kW | ||||
| ASW LT-G3 25-40kW | ||||
| ASW LT 75-110kW | ||||
| ASW HT 250-360kW |
For the communication board documented in Solplanet quick guide QG0095_ASW05-12kH-T2-T3_EN_540-500534-01_V02_0425, page 19, use the Monitor RJ45 port 3: pin 1 is RS485A, pin 2 is RS485B and pin 3 is GND. Pin 4 is unused. This differs from the LT-G2 Pro diagram below; do not use that diagram to select the H-T2 ground pin.
Match the inverter's configured Modbus address. The physically verified connection used 9600 baud, 8 data bits, no parity and 1 stop bit. A working test at one address does not mean that every inverter has the same address. Follow the model-specific Solplanet instructions and the RS485 wiring guidelines for bus termination and use secured, insulated terminals rather than exposed resistor leads.
The SmartgridOne Controller and the ASW LT-G2 Pro 3-20kW Solplanet inverter communicate via RS485.
| Device | SmartgridOne Controller model OM1 | SmartgridOne Controller model IG8 | RS485-USB converter | RS485-Ethernet converter |
|---|---|---|---|---|
| TX_RS485A | RS485 A | RS485_POS | RS485 A | TX+ |
| TX_RS485B | RS485 B | RS485_NEG | RS485 B | TX- |
| GND | RS GND | GND | Not available | G |
